CAT 320C 287-0118 Parts Manual Diagram - ADAPTER AS

Home › Parts Manual › CAT 320C › 287-0118

Part No.

287-0118

Name (EN)

ADAPTER AS

Name (CN)

Qty

1 per assembly

Group

162-6184

System

AIR INLET AND EXHAUST SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 83 of official CAT 320C parts manual

Part No.	Name	Qty	Page
8T-4121	WASHER	1	83
8T-4191	BOLT (L=16mm)	1	83
171-9072	PIPE AS	1	83
5P-4961	CLAMP	1	83
096-0061	STRAP	1	83
5P-1442	HOSE (69cm)	1	83
171-9073	CLIP	1	83
8T-4121	WASHER	1	84
8T-4191	BOLT (L=16mm)	1	84
171-9072	PIPE AS	1	84
5P-4961	CLAMP	1	84
096-0061	STRAP	1	84
5P-1442	HOSE (69cm)	1	84
171-9073	CLIP	1	84
8T-4121	WASHER	1	63
8T-4191	BOLT (L=16mm)	1	63
171-9072	PIPE AS	1	63
5P-4961	CLAMP	1	63
096-0061	STRAP	1	63
5P-1442	HOSE (69cm)	1	63
171-9073	CLIP	1	63
8T-4121	WASHER	1	82
8T-4191	BOLT (L=16mm)	1	82
171-9072	PIPE AS	1	82
5P-4961	CLAMP	1	82
096-0061	STRAP	1	82
5P-1442	HOSE (69cm)	1	82
171-9073	CLIP	1	82
