| Part No. | Name | Qty | Page |
|---|---|---|---|
| 087-5845 |
PIN
|
1 | 1071 |
| 087-5802 |
LINK
|
1 | 1071 |
| 166-1581 |
LINK AS
|
1 | 1071 |
| 240-2913 |
BEARING
|
2 | 1071 |
| 240-2912 |
BEARING
|
2 | 1071 |
| 8T-4132 |
NUT
|
4 | 1071 |
| 096-0854 |
SEAL
|
6 | 1071 |
| 087-5805 |
PIN
|
2 | 1071 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 1071 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 1071 |
| 3B-8489 |
FITTING
|
5 | 1071 |
| 087-5806 |
PIN
|
1 | 1071 |
| 087-5803 |
LINK AS
|
1 | 1071 |
| 168-2629 |
RING
|
2 | 1071 |
| 168-2628 |
PIN
|
2 | 1071 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 1071 |
| 087-5845 |
PIN
|
1 | 965 |
| 087-5802 |
LINK
|
1 | 965 |
| 166-1581 |
LINK AS
|
1 | 965 |
| 137-2919 |
BEARING
|
2 | 965 |
| 143-3841 |
BEARING
|
2 | 965 |
| 8T-4132 |
NUT
|
4 | 965 |
| 096-0854 |
SEAL
|
6 | 965 |
| 087-5805 |
PIN
|
2 | 965 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 965 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 965 |
| 3B-8489 |
FITTING
|
5 | 965 |
| 087-5806 |
PIN
|
1 | 965 |
| 087-5803 |
LINK AS
|
1 | 965 |
| 168-2629 |
RING
|
2 | 965 |
| 168-2628 |
PIN
|
2 | 965 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 965 |
| 087-5845 |
PIN
|
1 | 752 |
| 087-5802 |
LINK
|
1 | 752 |
| 166-1581 |
LINK AS
|
1 | 752 |
| 137-2919 |
BEARING
|
2 | 752 |
| 143-3841 |
BEARING
|
2 | 752 |
| 8T-4132 |
NUT
|
4 | 752 |
| 096-0854 |
SEAL
|
6 | 752 |
| 087-5805 |
PIN
|
2 | 752 |
| 7X-2558 |
BOLT (L=150mm)
|
2 | 752 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 752 |
| 3B-8489 |
FITTING
|
5 | 752 |
| 087-5806 |
PIN
|
1 | 752 |
| 087-5803 |
LINK AS
|
1 | 752 |
| 168-2629 |
RING
|
2 | 752 |
| 168-2628 |
PIN
|
2 | 752 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 752 |
| 087-5845 |
PIN
|
1 | 931 |
| 087-5802 |
LINK
|
1 | 931 |
