| Part No. | Name | Qty | Page |
|---|---|---|---|
| 250-2488 |
250-2488
|
1 | 813 |
| 121-1491 |
121-1491
|
1 | 813 |
| 158-8206 |
HOUSING
|
1 | 814 |
| 8T-6759 |
PLUG
|
2 | 814 |
| 8T-4195 |
BOLT (L=30mm)
|
20 | 814 |
| 8T-4121 |
WASHER
|
24 | 814 |
| 158-8159 |
HOUSING
|
4 | 814 |
| 121-1491 |
VALVE GP
|
1 | 814 |
| 7I-2272 |
BOLT (L=12mm)
|
2 | 814 |
| 6E-2274 |
COVER
|
5 | 814 |
| 8T-6685 |
BOLT (L=110mm)
|
4 | 814 |
| 6E-3653 |
PLUG
|
1 | 814 |
| 4I-3569 |
RING
|
1 | 814 |
| 7Y-5219 |
SEAL - O - RING (ID=12.37mm)
|
1 | 814 |
| 165-9595 |
COVER
|
1 | 814 |
| 9S-4180 |
PLUG
|
3 | 814 |
| 4J-7533 |
SEAL - O - RING (ID=6.07mm)
|
3 | 814 |
| 4J-5309 |
SEAL - O - RING (ID=9.19mm)
|
1 | 814 |
| 6E-5643 |
VALVE
|
1 | 814 |
| 4T-3148 |
SPRING
|
1 | 814 |
| 250-2446 |
PLUG
|
1 | 814 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
4 | 814 |
| 153-5295 |
VALVE GP
|
1 | 814 |
| 264-9961 |
PLUG
|
1 | 814 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
2 | 814 |
| 153-5306 |
SPRING
|
1 | 814 |
| 250-2508 |
VALVE GP
|
1 | 814 |
| 153-5298 |
SLEEVE
|
1 | 814 |
| 153-5299 |
VALVE
|
1 | 814 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 814 |
| 153-5291 |
CONNECTOR
|
1 | 814 |
| 2M-9780 |
SEAL - O - RING (ID=19.18mm)
|
1 | 814 |
| 236-6421 |
PLUG
|
1 | 814 |
| 6V-3922 |
SEAL - O - RING (ID=18.72mm)
|
1 | 814 |
| 153-5293 |
SPRING
|
1 | 814 |
| 153-5292 |
VALVE
|
1 | 814 |
| 153-5288 |
SPRING
|
1 | 814 |
| 153-5289 |
GUIDE
|
1 | 814 |
| 153-5290 |
PLUG
|
2 | 814 |
| 153-5311 |
SPRING
|
1 | 814 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
1 | 814 |
| 123-2485 |
PLUG
|
1 | 814 |
| 095-1575 |
SEAL - O - RING (ID=7.80mm)
|
1 | 814 |
| 095-1778 |
RING
|
1 | 814 |
| 7X-2621 |
BOLT (L=12mm)
|
1 | 814 |
| 103-8173 |
SEAL - O - RING (ID=31.70mm)
|
1 | 814 |
| 158-8150 |
VALVE GP
|
1 | 814 |
| 095-1787 |
RING
|
1 | 814 |
| 4I-6397 |
RING
|
1 | 814 |
| 6V-5556 |
SEAL - O - RING (ID=25.07mm)
|
1 | 814 |
