CAT 320C 236-6281 Parts Manual Diagram - STICK AS

Home › Parts Manual › CAT 320C › 236-6281

Part No.

236-6281

Name (EN)

STICK AS

Name (CN)

Qty

1 per assembly

Group

163-3542

System

IMPLEMENTS

Source

CAT Official Parts Manual

※ Click image to zoom · Page 1060 of official CAT 320C parts manual

Part No.	Name	Qty	Page
240-2915	BEARING	2	1060
229-1096	BEARING	2	1060
163-3744	BEARING	2	1060
3B-8489	FITTING	3	1060
166-1495	SEAL	2	1060
093-1434	SEAL	2	1060
4I-4811	PIN AS	1	1060
8T-4780	BOLT (L=30mm)	2	1060
8T-4123	WASHER	2	1060
093-0349	WASHER	2	1060
166-1494	SEAL	2	1060
093-0363	SPACER	1	1060
166-1486	SHIM (T=2.00mm)	2	1060
4I-4809	PIN AS	1	1060
118-5982	SPACER	1	1060
172-2984	STICK AS	1	956
137-2820	BEARING	2	956
163-3749	BEARING	2	956
163-3744	BEARING	2	956
3B-8489	FITTING	3	956
166-1495	SEAL	2	956
093-1434	SEAL	2	956
4I-4811	PIN AS	1	956
8T-4780	BOLT (L=30mm)	2	956
8T-4123	WASHER	2	956
093-0349	WASHER	2	956
166-1494	SEAL	2	956
093-0363	SPACER	1	956
166-1486	SHIM (T=2.00mm)	2	956
4I-4809	PIN AS	1	956
118-5982	SPACER	1	956
