| Part No. | Name | Qty | Page |
|---|---|---|---|
| 222-0152 |
222-0152
|
1 | 1009 |
| 9X-8256 |
WASHER
|
2 | 1010 |
| 8T-4971 |
BOLT (L=30mm)
|
1 | 1010 |
| 6D-1641 |
CLIP
|
13 | 1010 |
| 8T-4137 |
BOLT (L=20mm)
|
14 | 1010 |
| 8T-4121 |
WASHER
|
14 | 1010 |
| 099-3649 |
BOLT (L=40mm)
|
1 | 1010 |
| 8T-4224 |
WASHER
|
7 | 1010 |
| 155-7024 |
SPACER
|
2 | 1010 |
| 178-5425 |
ELBOW
|
1 | 1010 |
| 5D-1026 |
CLAMP
|
4 | 1010 |
| 095-0913 |
CLIP
|
2 | 1010 |
| 8T-3647 |
BOLT (L=80mm)
|
1 | 1010 |
| 5P-0767 |
HOSE (350cm)
|
1 | 1010 |
| 189-2787 |
GUARD
|
4 | 1010 |
| 3S-2093 |
STRAP
|
4 | 1010 |
| 201-4565 |
HOSE AS
|
1 | 1010 |
| 185-8110 |
SEAL - O - RING (ID=7.70mm)
|
2 | 1010 |
| 5C-2890 |
NUT
|
1 | 1010 |
| 6V-7357 |
BOLT (L=25mm)
|
1 | 1010 |
| 225-5738 |
HOSE AS
|
1 | 1010 |
| 7I-6601 |
SEAL - O - RING (ID=6.73mm)
|
2 | 1010 |
| 086-0950 |
BRACKET AS
|
1 | 1010 |
| 8T-4200 |
BOLT (L=16mm)
|
3 | 1010 |
| 164-0622 |
RECEIVER AS
|
1 | 1010 |
| 201-4566 |
HOSE AS
|
1 | 1010 |
| 105-9409 |
SEAL - O - RING (ID=15.88mm)
|
1 | 1010 |
| 185-8109 |
SEAL - O - RING (ID=16.20mm)
|
1 | 1010 |
| 105-9410 |
SEAL - O - RING (ID=10.80mm)
|
2 | 1010 |
| 7H-3937 |
LOCKWASHER
|
2 | 1010 |
| 7X-2537 |
BOLT (L=35mm)
|
1 | 1010 |
| 7X-0818 |
BOLT (L=45mm)
|
1 | 1010 |
| 171-7476 |
GROMMET
|
1 | 1010 |
| 145-0603 |
GROMMET
|
1 | 1010 |
| 145-8495 |
GUARD (36cm 2)
|
1 | 1010 |
| 4I-4579 |
NIPPLE
|
1 | 1010 |
| 145-8494 |
GUARD (30cm 2)
|
1 | 1010 |
| 201-4434 |
SUPPORT AS
|
1 | 1010 |
| 6D-4244 |
CLIP
|
1 | 1010 |
| 5P-0767 |
HOSE (310cm)
|
1 | 1010 |
| 145-8495 |
GUARD (40cm 2)
|
1 | 1010 |
