| Part No. | Name | Qty | Page |
|---|---|---|---|
| 204-0951 |
HOSE
|
1 | 56 |
| 204-0952 |
HOSE
|
1 | 56 |
| 7Y-1976 |
HOSE (40cm)
|
1 | 56 |
| 7X-2554 |
BOLT (L=70mm)
|
4 | 56 |
| 178-6450 |
SPACER
|
4 | 56 |
| 096-4035 |
CLIP
|
1 | 56 |
| 171-9077 |
BAND
|
1 | 56 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 56 |
| 8T-4224 |
WASHER
|
2 | 56 |
| 096-0061 |
STRAP
|
3 | 56 |
| 096-0744 |
TANK AS
|
1 | 56 |
| 171-3369 |
CAP AS
|
1 | 56 |
| 8T-4137 |
BOLT (L=20mm)
|
10 | 56 |
| 8T-4121 |
WASHER
|
1 | 56 |
| 3P-9847 |
CLIP
|
1 | 56 |
| 5P-9909 |
SEAL (0.14m)
|
1 | 56 |
| 204-0953 |
GUARD AS
|
1 | 56 |
| 7X-7729 |
WASHER
|
9 | 56 |
| 204-1035 |
GUARD AS
|
1 | 56 |
| 8T-4984 |
CLAMP
|
4 | 56 |
| 5P-8309 |
SEAL (0.905m)
|
1 | 56 |
| 5P-9909 |
SEAL (0.835m)
|
1 | 56 |
| 265-3562 |
265-3562
|
1 | 57 |
| 204-0951 |
HOSE
|
1 | 58 |
| 204-0952 |
HOSE
|
1 | 58 |
| 265-3562 |
RADIATOR GP
|
1 | 58 |
| 7Y-1976 |
HOSE (40cm)
|
1 | 58 |
| 7X-2554 |
BOLT (L=70mm)
|
4 | 58 |
| 178-6450 |
SPACER
|
4 | 58 |
| 096-4035 |
CLIP
|
1 | 58 |
| 171-9077 |
BAND
|
1 | 58 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 58 |
| 8T-4224 |
WASHER
|
2 | 58 |
| 096-0061 |
STRAP
|
3 | 58 |
| 096-0744 |
TANK AS
|
1 | 58 |
| 171-3369 |
CAP AS
|
1 | 58 |
| 8T-4137 |
BOLT (L=20mm)
|
10 | 58 |
| 8T-4121 |
WASHER
|
1 | 58 |
| 3P-9847 |
CLIP
|
1 | 58 |
| 5P-9909 |
SEAL (0.14m)
|
1 | 58 |
| 204-0953 |
GUARD AS
|
1 | 58 |
| 7X-7729 |
WASHER
|
9 | 58 |
| 204-1035 |
GUARD AS
|
1 | 58 |
| 8T-4984 |
CLAMP
|
4 | 58 |
| 5P-8309 |
SEAL (0.905m)
|
1 | 58 |
| 5P-9909 |
SEAL (0.835m)
|
1 | 58 |
| 265-3562 |
265-3562
|
1 | 59 |
| 204-0951 |
HOSE
|
1 | 60 |
| 204-0952 |
HOSE
|
1 | 60 |
| 265-3562 |
RADIATOR GP
|
1 | 60 |
