| Part No. | Name | Qty | Page |
|---|---|---|---|
| 164-0486 |
164-0486
|
1 | 1013 |
| 167-7083 |
SENSOR
|
1 | 1014 |
| 217-9362 |
PANEL AS
|
1 | 1014 |
| 214-4393 |
HARNESS AS
|
1 | 1014 |
| 163-6795 |
STRAP
|
2 | 1014 |
| 3S-2093 |
STRAP
|
2 | 1014 |
| 8T-4200 |
BOLT (L=16mm)
|
1 | 1014 |
| 8T-4224 |
WASHER
|
1 | 1014 |
| 176-1917 |
SENSOR
|
1 | 1014 |
| 8T-0286 |
BOLT (L=8mm)
|
2 | 1014 |
| 8T-0328 |
WASHER
|
2 | 1014 |
| 164-0486 |
HEATER GP
|
1 | 1014 |
| 7X-7729 |
WASHER
|
1 | 1014 |
| 170-9711 |
GROMMET
|
1 | 1014 |
| 8T-4137 |
BOLT (L=20mm)
|
6 | 1014 |
| 8T-4121 |
WASHER
|
5 | 1014 |
| 164-0483 |
164-0483
|
1 | 914 |
| 164-0486 |
164-0486
|
1 | 914 |
| 167-7083 |
SENSOR
|
1 | 915 |
| 217-9362 |
PANEL AS
|
1 | 915 |
| 176-1918 |
HARNESS AS
|
1 | 915 |
| 163-6795 |
STRAP
|
2 | 915 |
| 3S-2093 |
STRAP
|
2 | 915 |
| 8T-4200 |
BOLT (L=16mm)
|
1 | 915 |
| 8T-4224 |
WASHER
|
1 | 915 |
| 176-1917 |
SENSOR
|
1 | 915 |
| 8T-0286 |
BOLT (L=8mm)
|
2 | 915 |
| 8T-0328 |
WASHER
|
2 | 915 |
| 164-0486 |
HEATER GP
|
1 | 915 |
| 7X-7729 |
WASHER
|
1 | 915 |
| 170-9711 |
GROMMET
|
1 | 915 |
| 8T-4137 |
BOLT (L=20mm)
|
6 | 915 |
| 8T-4121 |
WASHER
|
5 | 915 |
| 178-5466 |
178-5466
|
1 | 714 |
| 164-0486 |
164-0486
|
1 | 714 |
| 167-7083 |
SENSOR
|
1 | 715 |
| 217-9362 |
PANEL AS
|
1 | 715 |
| 176-1918 |
HARNESS AS
|
1 | 715 |
| 163-6795 |
STRAP
|
2 | 715 |
| 3S-2093 |
STRAP
|
2 | 715 |
| 8T-4200 |
BOLT (L=16mm)
|
1 | 715 |
| 8T-4224 |
WASHER
|
1 | 715 |
| 176-1917 |
SENSOR
|
1 | 715 |
| 8T-0286 |
BOLT (L=8mm)
|
2 | 715 |
| 8T-0328 |
WASHER
|
2 | 715 |
| 164-0486 |
HEATER GP
|
1 | 715 |
| 7X-7729 |
WASHER
|
1 | 715 |
| 170-9711 |
GROMMET
|
1 | 715 |
| 8T-4137 |
BOLT (L=20mm)
|
6 | 715 |
| 8T-4121 |
WASHER
|
5 | 715 |
