| Part No. | Name | Qty | Page |
|---|---|---|---|
| 193-2696 |
193-2696
|
1 | 58 |
| 196-8185 |
FRAME AS
|
1 | 59 |
| 7Y-1976 |
HOSE (190cm)
|
1 | 59 |
| 096-4035 |
CLIP
|
2 | 59 |
| 193-2768 |
CAP AS
|
1 | 59 |
| 193-2767 |
CORE AS (RADIATOR)
|
1 | 59 |
| 193-2769 |
SEAL
|
2 | 59 |
| 193-2693 |
SEAL
|
2 | 59 |
| 8T-4189 |
BOLT (L=20mm)
|
12 | 59 |
| 8T-4224 |
WASHER
|
16 | 59 |
| 8T-4179 |
BOLT (L=20mm)
|
1 | 59 |
| 8T-4223 |
WASHER
|
1 | 59 |
| 196-8188 |
PLATE
|
1 | 59 |
| 8T-4138 |
BOLT (L=20mm)
|
2 | 59 |
| 9X-8256 |
WASHER
|
2 | 59 |
| 183-8111 |
SEAL
|
1 | 59 |
| 183-8103 |
SHROUD AS
|
1 | 59 |
| 196-8184 |
CORE AS (OIL COOLER)
|
1 | 59 |
| 196-8186 |
SCREEN AS
|
1 | 59 |
| 193-2765 |
SUPPORT AS
|
2 | 59 |
| 183-8106 |
SUPPORT AS
|
1 | 59 |
| 196-8201 |
NUT
|
1 | 59 |
| 196-8187 |
SCREEN AS
|
1 | 59 |
| 8T-4200 |
BOLT (L=16mm)
|
8 | 59 |
| 124-1574 |
COCK AS
|
1 | 59 |
| 8T-4137 |
BOLT (L=20mm)
|
4 | 59 |
| 8T-4121 |
WASHER
|
4 | 59 |
| 193-2764 |
HANDLE AS
|
1 | 59 |
| 096-4034 |
BOLT
|
4 | 59 |
| 183-8110 |
SEAL
|
2 | 59 |
| 5P-4116 |
WASHER
|
4 | 59 |
| 7Y-1976 |
HOSE (8cm)
|
1 | 59 |
