| Part No. | Name | Qty | Page |
|---|---|---|---|
| 216-6491 |
TUBE AS
|
1 | 570 |
| 216-6492 |
TUBE AS
|
1 | 570 |
| 177-8407 |
HOSE AS
|
2 | 570 |
| 5Q-4212 |
CLIP
|
8 | 570 |
| 093-1294 |
CLAMP
|
1 | 570 |
| 8T-4139 |
BOLT (L=30mm)
|
8 | 570 |
| 8T-4223 |
WASHER
|
8 | 570 |
| 8T-4186 |
BOLT (L=40mm)
|
1 | 570 |
| 8T-4121 |
WASHER
|
1 | 570 |
| 6V-8554 |
NUT
|
2 | 570 |
| 6V-8935 |
REDUCER
|
2 | 570 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
4 | 570 |
| 216-6491 |
TUBE AS
|
1 | 461 |
| 216-6492 |
TUBE AS
|
1 | 461 |
| 177-8407 |
HOSE AS
|
2 | 461 |
| 5Q-4212 |
CLIP
|
8 | 461 |
| 093-1294 |
CLAMP
|
1 | 461 |
| 8T-4139 |
BOLT (L=30mm)
|
8 | 461 |
| 8T-4223 |
WASHER
|
8 | 461 |
| 8T-4186 |
BOLT (L=40mm)
|
1 | 461 |
| 8T-4121 |
WASHER
|
1 | 461 |
| 6V-8554 |
NUT
|
2 | 461 |
| 6V-8935 |
REDUCER
|
2 | 461 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
4 | 461 |
| 216-6491 |
TUBE AS
|
1 | 409 |
| 216-6492 |
TUBE AS
|
1 | 409 |
| 177-8407 |
HOSE AS
|
2 | 409 |
| 5Q-4212 |
CLIP
|
8 | 409 |
| 093-1294 |
CLAMP
|
1 | 409 |
| 8T-4139 |
BOLT (L=30mm)
|
8 | 409 |
| 8T-4223 |
WASHER
|
8 | 409 |
| 8T-4186 |
BOLT (L=40mm)
|
1 | 409 |
| 8T-4121 |
WASHER
|
1 | 409 |
| 6V-8554 |
NUT
|
2 | 409 |
| 6V-8935 |
REDUCER
|
2 | 409 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
4 | 409 |
| 216-6491 |
TUBE AS
|
1 | 545 |
| 216-6492 |
TUBE AS
|
1 | 545 |
| 177-8407 |
HOSE AS
|
2 | 545 |
| 5Q-4212 |
CLIP
|
8 | 545 |
| 093-1294 |
CLAMP
|
1 | 545 |
| 8T-4139 |
BOLT (L=30mm)
|
8 | 545 |
| 8T-4223 |
WASHER
|
8 | 545 |
| 8T-4186 |
BOLT (L=40mm)
|
1 | 545 |
| 8T-4121 |
WASHER
|
1 | 545 |
| 6V-8554 |
NUT
|
2 | 545 |
| 6V-8935 |
REDUCER
|
2 | 545 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
4 | 545 |
