CAT 320C 187-9821 Parts Manual Diagram - TUBE AS

Home › Parts Manual › CAT 320C › 187-9821

Part No.

187-9821

Name (EN)

TUBE AS

Name (CN)

Qty

1 per assembly

Group

187-9815

System

HYDRAULIC SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 403 of official CAT 320C parts manual

Part No.	Name	Qty	Page
6V-8398	SEAL - O - RING (OD=16.03mm)	2	403
149-1738	CLIP	2	403
8T-7929	BOLT (L=180mm)	2	403
8T-4223	WASHER	6	403
187-9833	PLATE	1	403
153-8867	CLIP	4	403
8T-4956	BOLT (L=35mm)	2	403
8T-4244	NUT	2	403
8T-4139	BOLT (L=30mm)	2	403
6V-8398	SEAL - O - RING (OD=16.03mm)	2	539
149-1738	CLIP	2	539
8T-7929	BOLT (L=180mm)	2	539
8T-4223	WASHER	6	539
187-9833	PLATE	1	539
153-8867	CLIP	4	539
8T-4956	BOLT (L=35mm)	2	539
8T-4244	NUT	2	539
8T-4139	BOLT (L=30mm)	2	539
