CAT 320C 185-2465 Parts Manual Diagram - COVER

Home › Parts Manual › CAT 320C › 185-2465

Part No.

185-2465

Name (EN)

COVER

Name (CN)

Qty

1 per assembly

Group

171-2654

System

ELECTRICAL AND STARTING SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 192 of official CAT 320C parts manual

Part No.	Name	Qty	Page
8T-4191	BOLT (L=16mm)	4	192
8T-4121	WASHER	4	192
171-2671	SUPPORT AS	1	192
157-3165	CONTROL GP	1	192
8T-2396	BOLT (L=60mm)	4	192
9X-8256	WASHER	4	192
8T-4200	BOLT (L=16mm)	2	192
8T-4224	WASHER	2	192
8T-4191	BOLT (L=16mm)	4	193
8T-4121	WASHER	4	193
195-8872	SUPPORT AS	1	193
157-3165	CONTROL GP	1	193
095-0645	BOLT (L=55mm)	4	193
9X-8256	WASHER	4	193
8T-4200	BOLT (L=16mm)	3	193
8T-4224	WASHER	3	193
195-8871	COVER	1	193
8T-4191	BOLT (L=16mm)	4	290
8T-4121	WASHER	4	290
195-8872	SUPPORT AS	1	290
157-3165	CONTROL GP	1	290
095-0645	BOLT (L=55mm)	4	290
9X-8256	WASHER	4	290
8T-4200	BOLT (L=16mm)	3	290
8T-4224	WASHER	3	290
195-8871	COVER	1	290
