| Part No. | Name | Qty | Page |
|---|---|---|---|
| 183-8119 |
HOSE
|
1 | 47 |
| 8T-4984 |
CLAMP
|
4 | 47 |
| 096-4035 |
CLIP
|
1 | 47 |
| 096-0744 |
TANK AS
|
1 | 47 |
| 171-3369 |
CAP AS
|
1 | 47 |
| 8T-4224 |
WASHER
|
2 | 47 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 47 |
| 171-9077 |
BAND
|
1 | 47 |
| 7Y-1976 |
HOSE (40cm)
|
1 | 47 |
| 5P-0815 |
SEAL (0.72m)
|
1 | 47 |
| 178-6450 |
SPACER
|
4 | 47 |
| 7X-2554 |
BOLT (L=70mm)
|
4 | 47 |
| 183-8120 |
HOSE
|
1 | 47 |
| 162-6224 |
BRACE
|
1 | 47 |
| 5P-1076 |
WASHER
|
1 | 47 |
| 8T-4192 |
BOLT (L=25mm)
|
1 | 47 |
| 162-6225 |
GUARD AS
|
1 | 47 |
| 162-6226 |
GUARD AS
|
1 | 47 |
| 7X-7729 |
WASHER
|
10 | 47 |
| 8T-4137 |
BOLT (L=20mm)
|
11 | 47 |
| 8T-4223 |
WASHER
|
1 | 47 |
| 8T-4139 |
BOLT (L=30mm)
|
1 | 47 |
| 8T-4244 |
NUT
|
1 | 47 |
| 8T-4121 |
WASHER
|
1 | 47 |
| 3P-9847 |
CLIP
|
1 | 47 |
| 096-0061 |
STRAP
|
3 | 47 |
| 5P-0815 |
SEAL (0.14m)
|
1 | 47 |
| 193-2766 |
193-2766
|
1 | 48 |
| 193-2851 |
HOSE
|
1 | 49 |
| 8T-4984 |
CLAMP
|
4 | 49 |
| 193-2766 |
RADIATOR GP
|
1 | 49 |
| 096-4035 |
CLIP
|
1 | 49 |
| 096-0744 |
TANK AS
|
1 | 49 |
| 171-3369 |
CAP AS
|
1 | 49 |
| 8T-4224 |
WASHER
|
2 | 49 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 49 |
| 171-9077 |
BAND
|
1 | 49 |
| 7Y-1976 |
HOSE (40cm)
|
1 | 49 |
| 5P-9909 |
SEAL (0.72m)
|
1 | 49 |
| 178-6450 |
SPACER
|
4 | 49 |
| 7X-2554 |
BOLT (L=70mm)
|
4 | 49 |
| 162-6223 |
HOSE
|
1 | 49 |
| 162-6224 |
BRACE
|
1 | 49 |
| 5P-1076 |
WASHER
|
1 | 49 |
| 8T-4192 |
BOLT (L=25mm)
|
1 | 49 |
| 162-6225 |
GUARD AS
|
1 | 49 |
| 162-6226 |
GUARD AS
|
1 | 49 |
| 7X-7729 |
WASHER
|
10 | 49 |
| 8T-4137 |
BOLT (L=20mm)
|
11 | 49 |
| 8T-4223 |
WASHER
|
1 | 49 |
