CAT 320C 178-6563 Parts Manual Diagram - STRAINER

Home › Parts Manual › CAT 320C › 178-6563

Part No.

178-6563

Name (EN)

STRAINER

Name (CN)

Qty

1 per assembly

Group

178-6524

System

LUBRICATION SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 49 of official CAT 320C parts manual

Part No.	Name	Qty	Page
5I-7640	SPRING	1	49
5I-7643	VALVE	1	49
5I-7644	PLUG	1	49
5I-7642	PLATE	1	49
9J-2089	WASHER	1	49
8T-4200	BOLT (L=16mm)	4	49
095-8638	WASHER	4	49
5I-5038	SEAL - O - RING (ID=24.40mm)	1	49
8T-4224	WASHER	3	49
5I-7640	SPRING	1	37
5I-7643	VALVE	1	37
5I-7644	PLUG	1	37
5I-7642	PLATE	1	37
9J-2089	WASHER	1	37
8T-4200	BOLT (L=16mm)	4	37
095-8638	WASHER	4	37
5I-5038	SEAL - O - RING (ID=24.40mm)	1	37
8T-4224	WASHER	3	37
5I-7640	SPRING	1	33
5I-7643	VALVE	1	33
5I-7644	PLUG	1	33
5I-7642	PLATE	1	33
9J-2089	WASHER	1	33
8T-4200	BOLT (L=16mm)	4	33
095-8638	WASHER	4	33
5I-5038	SEAL - O - RING (ID=24.40mm)	1	33
8T-4224	WASHER	3	33
5I-7640	SPRING	1	48
5I-7643	VALVE	1	48
5I-7644	PLUG	1	48
5I-7642	PLATE	1	48
9J-2089	WASHER	1	48
8T-4200	BOLT (L=16mm)	4	48
095-8638	WASHER	4	48
5I-5038	SEAL - O - RING (ID=24.40mm)	1	48
8T-4224	WASHER	3	48
