CAT 320C 178-6556 Parts Manual Diagram - COVER

Home › Parts Manual › CAT 320C › 178-6556

Part No.

178-6556

Name (EN)

COVER

Name (CN)

Qty

1 per assembly

Group

178-6521

System

AIR INLET AND EXHAUST SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 86 of official CAT 320C parts manual

Part No.	Name	Qty	Page
178-6554	STUD	4	86
5I-7742	GASKET	1	86
178-6552	MANIFOLD	1	86
5I-7549	STUD	12	86
095-8638	WASHER	18	86
178-6553	GASKET	2	86
5I-7633	NUT	8	86
5I-7550	SPACER	11	86
5I-7601	SPACER	1	86
5I-8013	WASHER	12	86
5C-7261	NUT	12	86
091-3474	NUT	1	86
178-6555	SUPPORT	1	86
8T-4200	BOLT (L=16mm)	5	86
8T-4224	WASHER	5	86
178-6554	STUD	4	65
5I-7742	GASKET	1	65
178-6552	MANIFOLD	1	65
5I-7549	STUD	12	65
095-8638	WASHER	19	65
178-6553	GASKET	2	65
5I-7633	NUT	8	65
5I-7550	SPACER	10	65
5I-7601	SPACER	2	65
5I-8013	WASHER	12	65
5C-7261	NUT	12	65
091-3474	NUT	2	65
178-6555	SUPPORT	1	65
8T-4200	BOLT (L=16mm)	5	65
8T-4224	WASHER	5	65
