| Part No. | Name | Qty | Page |
|---|---|---|---|
| 178-6543 |
RING SET (STANDARD)
|
6 | 28 |
| 178-6544 |
RING SET (OS=0.25mm)
|
6 | 28 |
| 178-6545 |
RING SET (OS=0.50mm)
|
6 | 28 |
| 178-6547 |
PISTON (OS=0.25mm)
|
6 | 28 |
| 178-6548 |
PISTON (OS=0.50mm)
|
6 | 28 |
| 094-7134 |
PIN
|
6 | 28 |
| 5I-7667 |
RING
|
12 | 28 |
| 5I-7668 |
ROD AS
|
6 | 28 |
| 5I-7539 |
BUSHING
|
1 | 28 |
| 094-7154 |
BOLT (L=85mm)
|
2 | 28 |
| 094-7516 |
NUT
|
2 | 28 |
| 5I-7637 |
BEARING (AVAILABLE IN SET WITH PAIR)
|
12 | 28 |
| 5I-7794 |
BEARING (US=0.25mm)
|
12 | 28 |
| 5I-7795 |
BEARING (US=0.50mm)
|
12 | 28 |
| 5I-7796 |
BEARING (US=0.75mm)
|
12 | 28 |
| 178-6543 |
RING SET (STANDARD)
|
6 | 24 |
| 178-6544 |
RING SET (OS=0.25mm)
|
6 | 24 |
| 178-6545 |
RING SET (OS=0.50mm)
|
6 | 24 |
| 178-6547 |
PISTON (OS=0.25mm)
|
6 | 24 |
| 178-6548 |
PISTON (OS=0.50mm)
|
6 | 24 |
| 094-7134 |
PIN
|
6 | 24 |
| 5I-7667 |
RING
|
12 | 24 |
| 5I-7668 |
ROD AS
|
6 | 24 |
| 5I-7539 |
BUSHING
|
1 | 24 |
| 094-7154 |
BOLT (L=85mm)
|
2 | 24 |
| 094-7516 |
NUT
|
2 | 24 |
| 5I-7637 |
BEARING (AVAILABLE IN SET WITH PAIR)
|
12 | 24 |
| 5I-7794 |
BEARING (US=0.25mm)
|
12 | 24 |
| 5I-7795 |
BEARING (US=0.50mm)
|
12 | 24 |
| 5I-7796 |
BEARING (US=0.75mm)
|
12 | 24 |
