CAT 320C 171-9159 Parts Manual Diagram - HOSE

Home › Parts Manual › CAT 320C › 171-9159

Part No.

171-9159

Name (EN)

HOSE

Name (CN)

Qty

1 per assembly

Group

171-9153

System

COOLING SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 45 of official CAT 320C parts manual

Part No.	Name	Qty	Page
183-8137	183-8137	1	42
183-8140	HOSE	1	43
5P-0815	SEAL (1.4dm)	1	43
183-8137	RADIATOR GP	1	43
096-4035	CLIP	1	43
7Y-1976	HOSE (85cm)	1	43
7X-2554	BOLT (L=70mm)	4	43
178-6450	SPACER	4	43
183-8141	HOSE	1	43
099-6607	BAND	1	43
8T-4200	BOLT (L=16mm)	2	43
8T-4224	WASHER	2	43
096-0061	STRAP	4	43
096-0744	TANK AS	1	43
171-3369	CAP AS	1	43
8T-4137	BOLT (L=20mm)	11	43
8T-4121	WASHER	1	43
3P-9847	CLIP	1	43
5P-0815	SEAL (7.2dm)	1	43
162-6225	GUARD AS	1	43
7X-7729	WASHER	10	43
162-6226	GUARD AS	1	43
8T-4984	CLAMP	4	43
193-2852	193-2852	1	44
193-2863	HOSE	1	45
5P-9909	SEAL (0.14m)	1	45
193-2852	RADIATOR GP	1	45
096-4035	CLIP	1	45
7Y-1976	HOSE (85cm)	1	45
7X-2554	BOLT (L=70mm)	4	45
178-6450	SPACER	4	45
099-6607	BAND	1	45
8T-4200	BOLT (L=16mm)	2	45
8T-4224	WASHER	2	45
096-0061	STRAP	4	45
096-0744	TANK AS	1	45
171-3369	CAP AS	1	45
8T-4137	BOLT (L=20mm)	11	45
8T-4121	WASHER	1	45
3P-9847	CLIP	1	45
5P-9909	SEAL (0.72m)	1	45
162-6225	GUARD AS	1	45
7X-7729	WASHER	10	45
162-6226	GUARD AS	1	45
8T-4984	CLAMP	4	45
