| Part No. | Name | Qty | Page |
|---|---|---|---|
| 094-0584 |
WASHER
|
6 | 752 |
| 094-1509 |
SHAFT
|
3 | 752 |
| 148-4733 |
GEAR (Z=26)
|
3 | 752 |
| 114-1581 |
SPACER
|
1 | 752 |
| 148-4732 |
GEAR (Z=20)
|
1 | 752 |
| 093-1729 |
RING
|
2 | 752 |
| 148-4632 |
GEAR (Z=23)
|
1 | 752 |
| 191-2578 |
CARRIER
|
1 | 752 |
| 7Y-1434 |
SPACER
|
1 | 752 |
| 148-4637 |
CARRIER
|
1 | 752 |
| 148-4640 |
RING
|
1 | 752 |
| 148-4643 |
BEARING
|
1 | 752 |
| 095-1022 |
BEARING
|
1 | 752 |
| 148-4642 |
SEAL - O - RING (ID=204.30mm)
|
1 | 752 |
| 227-6228 |
CAGE
|
1 | 752 |
| 8T-4183 |
BOLT (L=40mm)
|
6 | 752 |
| 8T-4223 |
WASHER
|
6 | 752 |
| 199-4561 |
SEAL
|
2 | 752 |
| 148-4636 |
SHAFT
|
1 | 752 |
| 148-4638 |
HOUSING
|
1 | 752 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 752 |
| 6V-7238 |
VALVE
|
1 | 752 |
| 148-4634 |
SHAFT
|
3 | 752 |
| 095-0891 |
PIN
|
3 | 752 |
| 148-4635 |
GEAR (Z=73)
|
1 | 752 |
| 148-4633 |
GEAR (Z=25)
|
3 | 752 |
| 7Y-0252 |
BEARING
|
6 | 752 |
| 094-0611 |
WASHER
|
6 | 752 |
| 095-0886 |
PIN
|
3 | 752 |
| 094-1516 |
BEARING
|
3 | 752 |
| 171-9383 |
SPACER
|
1 | 752 |
| 094-0584 |
WASHER
|
6 | 671 |
| 094-1509 |
SHAFT
|
3 | 671 |
| 148-4733 |
GEAR (Z=26)
|
3 | 671 |
| 114-1581 |
SPACER
|
1 | 671 |
| 148-4732 |
GEAR (Z=20)
|
1 | 671 |
| 093-1729 |
RING
|
2 | 671 |
| 148-4632 |
GEAR (Z=23)
|
1 | 671 |
| 191-2578 |
CARRIER
|
1 | 671 |
| 7Y-1434 |
SPACER
|
1 | 671 |
| 148-4637 |
CARRIER
|
1 | 671 |
| 148-4640 |
RING
|
1 | 671 |
| 148-4643 |
BEARING
|
1 | 671 |
| 095-1022 |
BEARING
|
1 | 671 |
| 148-4642 |
SEAL - O - RING (ID=204.30mm)
|
1 | 671 |
| 148-4639 |
CAGE
|
1 | 671 |
| 8T-4183 |
BOLT (L=40mm)
|
6 | 671 |
| 8T-4223 |
WASHER
|
6 | 671 |
| 199-4561 |
SEAL
|
2 | 671 |
| 148-4636 |
SHAFT
|
1 | 671 |
