CAT 320C 120-7724 Parts Manual Diagram - CONNECTOR

Home › Parts Manual › CAT 320C › 120-7724

Part No.

120-7724

Name (EN)

CONNECTOR

Name (CN)

Qty

1 per assembly

Group

170-6829

System

ELECTRICAL AND STARTING SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 274 of official CAT 320C parts manual

Part No.	Name	Qty	Page
2L-8075	TERMINAL	4	274
7Y-3950	TERMINAL	4	274
2L-8075	TERMINAL	4	171
7Y-3950	TERMINAL	4	171
2L-8075	TERMINAL	4	171
7Y-3950	TERMINAL	4	171
6V-8362	SCREW	4	172
9B-7233	LOCKWASHER	4	172
7T-6799	NUT	1	172
2L-8075	TERMINAL	4	156
7Y-3950	TERMINAL	4	156
2L-8075	TERMINAL	4	156
7Y-3950	TERMINAL	4	156
6V-8362	SCREW	4	157
9B-7233	LOCKWASHER	4	157
7T-6799	NUT	1	157
2L-8075	TERMINAL	4	251
7Y-3950	TERMINAL	4	251
2L-8075	TERMINAL	4	251
7Y-3950	TERMINAL	4	251
6V-8362	SCREW	4	252
9B-7233	LOCKWASHER	4	252
7T-6799	NUT	1	252

Need price and stock for 120-7724? WSTPARTS supplies genuine CAT parts globally with fast delivery.
