| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 7C-1445 |
COVER
|
2 | 51 |
| 229-3569 |
HOUSING
|
1 | 51 |
| 061-9455 |
SEAL - O - RING (ID=47.22mm)
|
1 | 51 |
| 3K-8460 |
PLUG
|
1 | 51 |
| 5P-7701 |
SEAL - O - RING (ID=29.74mm)
|
1 | 51 |
| 5P-7814 |
SEAL - O - RING (ID=10.52mm)
|
1 | 51 |
| 5P-8245 |
WASHER
|
14 | 51 |
| 6V-5219 |
BOLT (L=40mm)
|
2 | 51 |
| 6V-8197 |
BOLT (L=40mm)
|
14 | 51 |
| 8L-2786 |
SEAL - O - RING (ID=16.36mm)
|
2 | 51 |
| 9M-1974 |
WASHER
|
2 | 51 |
| 9S-4185 |
PLUG
|
2 | 51 |
| 9S-9334 |
PLUG
|
1 | 51 |
| 1U-8846 |
GASKET MAKER
|
1 | 51 |
| 224-9843 |
224-9843
|
1 | 51 |
| 7C-1445 |
COVER
|
2 | 52 |
| 229-3569 |
HOUSING
|
1 | 52 |
| 061-9455 |
SEAL - O - RING (ID=47.22mm)
|
1 | 52 |
| 3K-8460 |
PLUG
|
1 | 52 |
| 5P-7701 |
SEAL - O - RING (ID=29.74mm)
|
1 | 52 |
| 5P-7814 |
SEAL - O - RING (ID=10.52mm)
|
1 | 52 |
| 5P-8245 |
WASHER
|
14 | 52 |
| 6V-5219 |
BOLT (L=40mm)
|
2 | 52 |
| 6V-8197 |
BOLT (L=40mm)
|
14 | 52 |
| 8L-2786 |
SEAL - O - RING (ID=16.36mm)
|
2 | 52 |
| 9M-1974 |
WASHER
|
2 | 52 |
| 9S-4185 |
PLUG
|
2 | 52 |
| 9S-9334 |
PLUG
|
1 | 52 |
| 1U-8846 |
GASKET MAKER
|
1 | 52 |
