| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 8T-5001 |
BOLT (L=130mm)
|
4 | 493 |
| 7X-2549 |
BOLT (L=100mm)
|
8 | 493 |
| 8T-4223 |
WASHER
|
34 | 493 |
| 149-6800 |
PIPE AS
|
1 | 493 |
| 4J-0527 |
SEAL - O - RING (ID=56.74mm)
|
6 | 493 |
| 152-9522 |
COVER
|
1 | 493 |
| 149-6798 |
PIPE AS
|
1 | 493 |
| 6J-2680 |
SEAL - O - RING (ID=69.44mm)
|
3 | 493 |
| 152-9543 |
BLOCK
|
1 | 493 |
| 152-9538 |
HOSE AS
|
1 | 493 |
| 4J-0522 |
SEAL - O - RING (ID=37.69mm)
|
3 | 493 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
8 | 493 |
| 6V-8778 |
TEE
|
1 | 493 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
3 | 493 |
| 6V-9877 |
ELBOW
|
2 | 493 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
2 | 493 |
| 6V-9846 |
TEE
|
1 | 493 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
5 | 493 |
| 8T-6356 |
TEE
|
1 | 493 |
| 148-4861 |
HOSE AS
|
1 | 493 |
| 4I-5636 |
HOSE AS
|
2 | 493 |
| 138-5090 |
HOSE AS
|
1 | 493 |
| 6V-9008 |
ELBOW
|
1 | 493 |
| 128-7568 |
HOSE AS
|
1 | 493 |
| 148-4832 |
PIPE AS
|
1 | 493 |
| 1P-4582 |
FLANGE
|
6 | 493 |
| 8T-4183 |
BOLT (L=40mm)
|
16 | 493 |
| 152-9535 |
HOSE AS
|
1 | 493 |
| 6V-9854 |
ELBOW
|
2 | 493 |
| 149-6699 |
SUPPORT
|
1 | 493 |
| 8T-5412 |
BOLT (L=140mm)
|
4 | 493 |
| 9S-6130 |
PLUG
|
1 | 493 |
| 2S-4078 |
SEAL - O - RING (ID=37.47mm)
|
1 | 493 |
| 8T-4121 |
WASHER
|
10 | 493 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 493 |
| 4J-0524 |
SEAL - O - RING (ID=47.22mm)
|
2 | 493 |
| 1P-4578 |
FLANGE
|
2 | 493 |
| 8T-4196 |
BOLT (L=35mm)
|
4 | 493 |
| 148-4788 |
SUPPORT
|
1 | 493 |
| 7Y-5247 |
U - BOLT
|
3 | 493 |
| 149-6702 |
SUPPORT AS
|
1 | 493 |
| 096-4883 |
NUT
|
6 | 493 |
| 5P-7468 |
CLIP
|
2 | 493 |
| 5P-7469 |
CLIP
|
2 | 493 |
| 5P-8444 |
GROMMET
|
2 | 493 |
| 087-5729 |
BLOCK
|
1 | 493 |
| 6V-9840 |
TEE
|
1 | 493 |
| 7G-9726 |
SPACER
|
1 | 493 |
| 8T-4184 |
BOLT (L=45mm)
|
1 | 493 |
| 7Y-8838 |
PIPE
|
1 | 493 |
