| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 5P-8249 |
WASHER-HARD (24X41.5X4-MM THK)
|
28 | 95 |
| 7X-7925 |
BOLT (7/8-14X11-IN)
|
28 | 95 |
| 223-1696 |
CAP-CRANKSHAFT BEARING
|
7 | 95 |
| 4W-4813 |
PLUG
|
3 | 95 |
| 8T-2929 |
SEAL-O-RING
|
3 | 95 |
| 8T-2928 |
SEAL-O-RING
|
3 | 95 |
| 211-7826 |
LINER-CYLINDER BLOCK
|
12 | 95 |
| 7N-2046 |
SEAL-O-RING
|
36 | 95 |
| 8N-4707 |
BAND-FILLER
|
12 | 95 |
| 100-8026 |
CYLINDER BLOCK AS
|
1 | 107 |
| 153-4906 |
SEAL-O-RING
|
6 | 107 |
| 1A-2029 |
BOLT (3/8-16X1.125-IN)
|
2 | 107 |
| 7X-7731 |
PLUG-PIPE (3/4-14-THD)
|
1 | 107 |
| 9S-4191 |
PLUG (9/16-18-THD)
|
6 | 107 |
| 2W-2940 |
PLUG
|
8 | 107 |
| 7N-2044 |
DOWEL
|
2 | 107 |
| 8T-6762 |
PLUG-PIPE (1/2-14-THD)
|
3 | 107 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
2 | 107 |
| 7N-2047 |
DOWEL
|
3 | 107 |
| 7X-4805 |
SEAL-O-RING
|
3 | 107 |
| 4N-0683 |
DOWEL
|
2 | 107 |
| 8T-6763 |
PLUG-PIPE (1/4-18-THD)
|
22 | 107 |
| 8T-2928 |
SEAL-O-RING
|
1 | 107 |
| 8T-0099 |
DOWEL
|
24 | 107 |
| 7N-5641 |
PLUG-MANIFOLD
|
2 | 107 |
| 197-7008 |
DOWEL
|
12 | 107 |
| 5P-0840 |
SEAL-O-RING
|
24 | 107 |
| 144-5692 |
GASKET-PLATE
|
12 | 107 |
| 110-6994 |
PLATE-SPACER
|
12 | 107 |
| 5F-9657 |
SEAL-O-RING
|
4 | 107 |
| 5P-8210 |
SEAL-O-RING
|
2 | 107 |
| 0S-1595 |
BOLT (1/2-13X1.25-IN)
|
2 | 107 |
| 5P-8245 |
WASHER-HARD (13.5X25.5X3-MM THK)
|
2 | 107 |
| 8N-8056 |
COVER
|
2 | 107 |
| 6V-3348 |
SEAL-O-RING
|
8 | 107 |
| 116-1359 |
BEARING-CAMSHAFT
|
14 | 107 |
| 4W-4814 |
ADAPTER
|
1 | 107 |
| 8T-2929 |
SEAL-O-RING
|
1 | 107 |
| 350-1413 |
CYLINDER BLOCK AS
|
1 | 109 |
| 1A-2029 |
BOLT (3/8-16X1.125-IN)
|
2 | 109 |
| 7X-7731 |
PLUG-PIPE (3/4-14-THD)
|
1 | 109 |
| 9S-4191 |
PLUG (9/16-18-THD)
|
6 | 109 |
| 2W-2940 |
PLUG
|
8 | 109 |
| 7N-2044 |
DOWEL
|
2 | 109 |
| 8T-6762 |
PLUG-PIPE (1/2-14-THD)
|
3 | 109 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
2 | 109 |
| 7N-2047 |
DOWEL
|
3 | 109 |
| 7X-4805 |
SEAL-O-RING
|
3 | 109 |
| 4N-0683 |
DOWEL
|
2 | 109 |
| 8T-6763 |
PLUG-PIPE (1/4-18-THD)
|
22 | 109 |
