| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 174-9570 |
174-9570
|
1 | 115 |
| 239-2396 |
239-2396
|
1 | 115 |
| 9Y-8389 |
GASKET
|
1 | 116 |
| 095-1386 |
CLAMP
|
5 | 116 |
| 134-6852 |
CONNECTOR
|
1 | 116 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 116 |
| 5P-4924 |
ELBOW
|
2 | 116 |
| 183-2824 |
PUMP GP
|
1 | 116 |
| 197-8391 |
SENSOR GP
|
1 | 116 |
| 212-2768 |
SWITCH GP (PRESSURE)
|
1 | 116 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 116 |
| 6V-4589 |
SEAL - O - RING (ID=19.18mm)
|
1 | 116 |
| 7L-9061 |
SEAL - O - RING (ID=18.72mm)
|
1 | 116 |
| 186-3735 |
PIN
|
2 | 116 |
| 229-0999 |
HOSE
|
1 | 116 |
| 237-9312 |
BASE AS
|
1 | 116 |
| 9S-4167 |
STUD
|
1 | 116 |
| 239-2396 |
SENSOR GP
|
1 | 116 |
| 248-9296 |
HOSE AS
|
1 | 116 |
| 250-6183 |
ADAPTER
|
1 | 116 |
| 256-1665 |
HOSE AS
|
1 | 116 |
| 256-1666 |
HOSE AS
|
1 | 116 |
| 262-2598 |
SUPPORT AS
|
1 | 116 |
| 8T-1715 |
ADAPTER
|
1 | 116 |
| 6V-8634 |
CONNECTOR
|
1 | 116 |
| 8T-1683 |
ELBOW
|
1 | 116 |
| 1R-0762 |
FILTER AS
|
1 | 116 |
| 2D-1290 |
GROMMET
|
3 | 116 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
7 | 116 |
| 5K-8451 |
CLIP
|
7 | 116 |
| 6K-8178 |
CLIP
|
4 | 116 |
| 6V-4589 |
SEAL - O - RING (ID=19.18mm)
|
1 | 116 |
| 8L-2786 |
SEAL - O - RING (ID=16.36mm)
|
3 | 116 |
| 8T-4121 |
WASHER
|
20 | 116 |
| 8T-4133 |
NUT
|
1 | 116 |
| 8T-4137 |
BOLT (L=20mm)
|
13 | 116 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 116 |
| 8T-4196 |
BOLT (L=35mm)
|
2 | 116 |
| 8T-4224 |
WASHER
|
1 | 116 |
| 8T-4971 |
BOLT (L=30mm)
|
1 | 116 |
| 8T-7547 |
BOLT (L=30mm)
|
1 | 116 |
| 9M-8406 |
CLIP
|
3 | 116 |
| 9S-8004 |
PLUG
|
5 | 116 |
| 9S-8005 |
PLUG
|
2 | 116 |
| 9X-8256 |
WASHER
|
1 | 116 |
| 7K-1181 |
STRAP
|
1 | 116 |
| 174-9570 |
FILTER GP
|
1 | 116 |
| 177-9778 |
BASE AS
|
1 | 116 |
| 9S-4167 |
STUD
|
1 | 116 |
| 5P-1076 |
WASHER
|
4 | 116 |
