| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 7W-0571 |
CONNECTION GP-GENERATOR LEADS
|
1 | 1430 |
| 9Y-4335 |
FILM (CSA CONTROL PANEL APPROVAL) (CONTROL PANEL) INSTALL INSIDE OF CONTROL PANEL
|
1 | 1430 |
| 4W-5138 |
FILM-INSTRUCTION (GROUND) INSTALL NEAR GENERATOR GROUND BOLT OR CUSTOMER CONNECTION POINT
|
1 | 1430 |
| 7W-4445 |
FILM-WARNING (DANGER VOLTAGE) INSTALL ONE ON RH & LH GENERATOR SIDE PANELS, LOCATE 4 TO 5 INCHES FROM REAR & TOP OF GENERATOR
|
2 | 1430 |
| 7W-0096 |
PLATE-INFORMATION (GENERATOR INFORMATION) (GENERATOR NAMEPLATE) INSTALL ON LH SIDE OF GENERATOR FRONT PANEL ASSEMBLY
|
1 | 1430 |
| 1W-7848 |
PLATE-SERIAL NUMBER (ENGLISH) INSTALL ON THE FRONT OF RH GENERATOR FOOT
|
1 | 1430 |
| 2K-3219 |
SCREW-DRIVE (NO 6X0.25-IN) USE TO INSTALL SERIAL NUMBER PLATE
|
2 | 1430 |
| 4P-3154 |
HEAT SINK
|
1 | 1475 |
| 4P-3153 |
SPACER (20.6X77X27.8-MM THK)
|
1 | 1475 |
| 1A-9579 |
BOLT (5/16-18X1.5-IN)
|
4 | 1475 |
| 4P-3468 |
ROTOR-EXCITER
|
1 | 1475 |
| 9Y-0916 |
RECTIFIER AS
|
1 | 1475 |
| 9Y-5817 |
STATOR-EXCITER
|
1 | 1475 |
| 4B-3903 |
BOLT (5/16-18X4-IN)
|
4 | 1475 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
8 | 1475 |
| 6I-0748 |
DEFLECTOR
|
3 | 1475 |
| 6I-0088 |
COVER AS-EXCITER
|
1 | 1475 |
| 1B-2714 |
BOLT (1/4-20X2.5-IN)
|
4 | 1475 |
| 5P-0537 |
WASHER-HARD (7.2X14.5X2-MM THK)
|
19 | 1475 |
| 111-2413 |
FAN-GENERATOR
|
1 | 1475 |
| 9S-8750 |
NUT-FULL (1/4-20-THD)
|
3 | 1475 |
| 7E-6574 |
COVER-DRIP
|
1 | 1475 |
| 0S-1615 |
BOLT (1/4-20X0.75-IN)
|
8 | 1475 |
| 7E-6577 |
COVER-RECTIFIER
|
1 | 1475 |
| 7C-5709 |
SLEEVE
|
3 | 1475 |
| 7C-5708 |
GROMMET
|
3 | 1475 |
| 033-2075 |
WASHER (0.266X1.25X0.06-IN THK)
|
6 | 1475 |
| 1N-7219 |
CHANNEL-RUBBER
|
1 | 1475 |
| 7E-6578 |
PANEL
|
2 | 1475 |
| 4W-9449 |
FILM-INFORMATION (GENERATOR WIRING DIAGRAM)
|
1 | 1475 |
| 7C-5711 |
FILM-INSTRUCTION (VOLTAGE CONTROL ADJUSTMENT)
|
1 | 1475 |
| 7E-6575 |
PANEL AS
|
1 | 1475 |
| 4F-8711 |
PLUG-BUTTON
|
2 | 1475 |
| 5N-3174 |
PLUG-BUTTON
|
8 | 1475 |
| 5N-3175 |
PLUG-BUTTON
|
1 | 1475 |
| 6K-9593 |
PLUG-BUTTON
|
1 | 1475 |
| 9F-7022 |
BOLT (1/4-20X1.5-IN)
|
1 | 1475 |
| 7E-6568 |
FRAME AS (RH)
|
1 | 1475 |
| 7E-6567 |
FRAME AS (LH)
|
1 | 1475 |
| 3V-5035 |
SPACER (0.302X0.54X1.03-IN THK)
|
1 | 1475 |
| 5L-2087 |
SPACER (9.25X13.72X50.8-MM THK)
|
4 | 1475 |
| 4P-3150 |
COVER AS
|
1 | 1475 |
| 5N-3167 |
SEAL-RING
|
3 | 1475 |
| 5N-3176 |
PLUG-BUTTON
|
3 | 1475 |
| 6D-7128 |
SEAL-O-RING
|
4 | 1475 |
| 8P-7065 |
PLUG-BUTTON
|
2 | 1475 |
| 8T-9587 |
SEAL-O-RING
|
2 | 1475 |
| 030-2284 |
PLUG-BUTTON
|
4 | 1475 |
| 6I-2737 |
RETAINER-BEARING
|
2 | 1475 |
| 110-6174 |
PANEL-REAR
|
1 | 1475 |
